Coaxial Guided Wave Radar Level Transmitter

Name: Coaxial Guided Wave Radar Level Transmitter
Brand: WELK Level

Coaxial guided wave radar option for low-dielectric liquids, small chambers and applications needing a contained signal path.

ProbeCoaxial / chamber style

FitClean low-dielectric liquids

Output4-20 mA / HART

UseSmall chambers

Request quote Attach files

Why choose· 01

Built for your duty.

Application-specific selection

small chambers, low-dielectric liquids, clean fluids and installations where the probe signal should be shielded from vessel internals

Technical configuration window

Range class, output, materials and accessories are presented as configurable options so WELK can match the page to the real process data before quotation.

Configuration before quotation

Coaxial probe diameter, length, chamber clearance, dielectric, viscosity and cleanability are checked before quote.

Limits kept visible

Coaxial probes are not suitable for dirty, sticky, crystallizing or solids service unless specifically reviewed.

Product details· 02

How it is selected & specified.

Coaxial Guided Wave Radar Level Transmitter is presented as a WELK Level configurable product family, not as a single fixed catalogue code. The page focuses on realistic selection logic, installation limits and RFQ data that should be checked before quotation.

Small chambers, low-dielectric liquids, clean fluids and installations where the probe signal should be shielded from vessel internals.

Coaxial probe diameter, length, chamber clearance, dielectric, viscosity and cleanability are checked before quote.

Coaxial probes are not suitable for dirty, sticky, crystallizing or solids service unless specifically reviewed.

Specifications· 03

Coaxial Guided Wave Radar Level Transmitter specification range.

Parameter	Value
Measuring principle	TDR guided wave radar with contained probe geometry
Probe style	Coaxial probe or chamber-style configuration by project
Media	Clean low-viscosity liquids after dielectric review
Output	4-20 mA, HART or digital by transmitter
Installation	Top insertion or chamber mounting by geometry
Use limit	Avoid dirty, sticky, crystallizing or solids service unless reviewed
RFQ data	Probe length, chamber ID, dielectric, viscosity, pressure and temperature

Applications· 04

Where this product works.

Bypass chambersClean chemical tanksLow dielectric liquidsSmall vesselsInterface review

Application

Chemical Storage Tanks

Chemical and petrochemical storage

Boilers & Process Vessels

Pressure vessels and thermal systems

Wetted materials & output options.

316L PTFEStainless SteelCustom rangeProcess connectionOutput signalLogo/MarkingDocumentation package

Send medium, range, tank geometry, process connection and output signal for model review.

Packaging & shipping· 05b

Export packing as standard.

Packed for export with protected sensor/probe surfaces, cable or antenna support, product label, wiring note and requested inspection or calibration documents.

Packaging and documents →

Spec siblings· 05c

Spec siblings & common coaxial guided wave radar level transmitter specs.

Measuring principle Probe style Media Output Installation Use limit

FAQ· 06

Coaxial Guided Wave Radar Level Transmitter questions.

Why use a coaxial probe?

It contains the signal path and can help with low-dielectric clean liquids or small chambers.

What are the main limits?

The medium must be clean enough that the coaxial gap does not clog or coat heavily.

What should I send for a quotation?

Send medium, measuring range, installation drawing or photo, process connection, output signal, power supply, environment and any certificate or document requirement.

Are final specifications fixed from this page?

No. Final range, accuracy, material, pressure, temperature, output and approval wording are confirmed from the selected order configuration.

Need coaxial guided wave radar level transmitter? Send the conditions.

Attach tank drawings, old instrument photos or datasheets if available.
